| Art No. | SIZE | WIRE | A | D | H | D1 | D2 | L | L1 | BL | Weight |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | tons | kg/pc | |
| S.RS16-02 | 2 | 2 | 5.5 | 4 | 8 | 5.5 | 2.2 | 55 | 24 | 0.5 | 0.024 |
| S.RS16-025 | 2.5 | 2.5 | 6.5 | 5 | 10 | 5.5 | 2.7 | 55 | 24 | 0.5 | 0.024 |
| S.RS16-03A | 3 | 3 | 8 | 5 | 10 | 6.35 | 3.3 | 55 | 28 | 0.8 | 0.025 |
| S.RS16-03B | 3 | 3 | 7.5 | 6 | 10 | 6.35 | 3.3 | 65 | 32 | 1.3 | 0.030 |
| S.RS16-03C | 3.2 | 3.2 | 7.5 | 5 | 9 | 6.35 | 3.5 | 65 | 38 | 0.8 | 0.020 |
| S.RS16-04A | 4 | 4 | 9 | 6 | 10 | 7.5 | 4.3 | 65 | 37 | 1.3 | 0.024 |
| S.RS16-04B | 4 | 4 | 11 | 8 | 11 | 7.5 | 4.3 | 77 | 40 | 2.35 | 0.047 |
| S.RS16-05A | 5 | 5 | 10 | 8 | 12 | 9 | 5.3 | 70 | 42 | 1.3 | 0.065 |
| S.RS16-05B | 5 | 5 | 12 | 9 | 14 | 9 | 5.3 | 88 | 57 | 2.35 | 0.074 |
| S.RS16-06A | 6 | 6 | 12 | 10 | 14 | 12.6 | 6.3 | 85 | 51 | 2.35 | 0.135 |
| S.RS16-06B | 6 | 6 | 14 | 12 | 20 | 12.6 | 6.4 | 106 | 63 | 4.7 | 0.160 |
| S.RS16-07 | 7 | 7 | 15 | 12 | 22 | 14.2 | 7.4 | 116 | 70 | 5.1 | 0.180 |
| S.RS16-08 | 8 | 8 | 17 | 16 | 26 | 16 | 8.4 | 145 | 85 | 7.6 | 0.400 |
| S.RS16-10 | 10 | 10 | 20 | 19 | 30 | 18 | 10.5 | 150 | 90 | 9.8 | 0.490 |
| S.RS16-12 | 12 | 12 | 20 | 19 | 30 | 20 | 12.6 | 195 | 105 | 13 | 0.640 |
| S.RS16-14 | 14 | 14 | 22 | 22 | 35 | 25 | 14.7 | 232 | 140 | 17 | 1.170 |
| S.RS16-16 | 16 | 16 | 25 | 25 | 38 | 28 | 16.9 | 264 | 160 | 24 | 1.540 |
| S.RS16-19 | 19 | 19 | 30 | 28 | 41 | 34.5 | 20 | 323 | 200 | 27 | 4.120 |
| S.RS16-22 | 22 | 22 | 35 | 32 | 52 | 40.5 | 23.2 | 350 | 230 | 31 | 5.700 |
| S.RS16-26 | 26 | 26 | 35 | 35 | 52 | 46 | 27.5 | 430 | 280 | 43 | 7.100 |
