Art No. | L1 mm | L2 mm | L3 mm | W1 mm | W2 mm | W3 mm | D1 mm | D2 mm | Chain Size mm |
S.M0302-22.6 | 22.60 | 8.70 | 90.00 | 14.80 | 10.00 | 27.60 | 8.80 | 7.00 | 6-8 |
S.M0302-28.0 | 28.00 | 10.50 | 115.00 | 17.80 | 13.00 | 38.50 | 10.60 | 10.60 | 8-10 |
Art No. | L1 mm | L2 mm | L3 mm | W1 mm | W2 mm | W3 mm | D1 mm | D2 mm | Chain Size mm |
S.M0302-22.6 | 22.60 | 8.70 | 90.00 | 14.80 | 10.00 | 27.60 | 8.80 | 7.00 | 6-8 |
S.M0302-28.0 | 28.00 | 10.50 | 115.00 | 17.80 | 13.00 | 38.50 | 10.60 | 10.60 | 8-10 |
